DS580F6 5
CS8406
DIGITAL INPUT CHARACTERISTICS
DIGITAL INTERFACE SPECIFICATIONS
(GND = 0 V; all voltages with respect to 0 V.)
TRANSMITTER CHARACTERISTICS
SWITCHING CHARACTERISTICS
(Inputs: Logic 0 = 0 V, Logic 1 = VL; C
L
= 20 pF)
Parameters Symbol Min Typ Max Units
Input Leakage Current I
in
- - ±0.5  A
Input Hysteresis (all inputs except OMCK) - 0.25 - V
Parameters Symbol Min Max Units
High-Level Output Voltage (I
OH
= -3.2 mA), except TXP/TXN V
OH
VL - 1.0 - V
Low-Level Output Voltage (I
OH
= 3.2 mA), except TXP/TXN V
OL
- 0.4 V
High-Level Output Voltage, TXP, TXN (21 mA at VL = 5.0 V)
(15 mA at VL = 3.3 V)
VL - 0.7
VL - 0.7
VL
VL
V
V
Low-Level Output Voltage, TXP, TXN (21 mA at VL = 5.0 V)
(16 mA at VL = 3.3 V)
-
-
0.7
0.7
V
V
High-Level Input Voltage VD = 5.0 V
VD = 3.3 V
V
IH
2.75
2.0
VL + 0.3
VL + 0.3
V
V
Low-Level Input Voltage VD = 5.0 V
VD = 3.3 V
V
IL
-0.3
-0.3
0.8
0.8
V
V
Parameters Symbol Typ Units
TXP Output Resistance VL = 5.0 V
VL = 3.3 V
R
TXP
26.5
33.5


TXN Output Resistance VL = 5.0 V
VL = 3.3 V
R
TXN
26.5
33.5


Parameter Symbol Min Typ Max Units
RST pin Low Pulse Width 200 - -  s
OMCK Frequency for OMCK = 512*Fs 4.1 - 98.4 MHz
OMCK Low and High Width for OMCK = 512*Fs 4.1 - - ns
OMCK Frequency for OMCK = 384*Fs 3.1 - 73.8 MHz
OMCK Low and High Width for OMCK = 384*Fs 6.1 - - ns
OMCK Frequency for OMCK = 256*Fs 2.0 - 49.2 MHz
OMCK Low and High Width for OMCK = 256*Fs 8.1 - - ns
OMCK Frequency for OMCK = 128*Fs 1.0 - 24.6 MHz
OMCK Low and High Width for OMCK = 128*Fs 18.3 - - ns
Frame Rate 8 - 192 kHz
AES3 Transmitter Output Jitter - 200 - ps RMS
