26

DS580F6

CS8406

SDA/CDOUT

1

Serial Control Data I/O (I²C Mode) / Data Out (SPI) (Input/Output) - In I²C Mode, SDA is the control I/O

data line. SDA is open drain and requires an external pull-up resistor to VL. In SPI Mode, CDOUT is the

output data from the control port interface on the CS8406

SCL/CCLK

28 Control Port Clock (

Input

) - Serial control interface clock and is used to clock control data bits into and

out of the CS8406. In I²C Mode, SCL requires an external pull-up resistor to VL.

AD0/CS

2

Address Bit 0 (I²C Mode) / Control Port Chip Select (SPI) (Input) - A falling edge on this pin puts the

CS8406 into SPI Control Port Mode. With no falling edge, the CS8406 defaults to I²C Mode. In I²C

Mode, AD0 is a chip address pin. In SPI Mode, CS is used to enable the control port interface on the

CS8406

AD1/CDIN

27 Address Bit 1 (I²C Mode) / Serial Control Data in (SPI) (

Input

) - In I²C Mode, AD1 is a chip address

pin. In SPI Mode, CDIN is the input data line for the control port interface.

AD2

3

Address Bit 2 (I²C Mode) (Input) - Determines the AD2 address bit for the control port in I²C Mode, and

should be connected to GND or VL. If SPI Mode is used, the AD2 pin should be connected to either

GND or VL.

RXP

4

Auxiliary AES3 Receiver Port (Input) - Input for an alternate, already AES3 coded, audio data source.

INT

19

Interrupt (Output) - Indicates key events during the operation of the CS8406. All bits affecting INT may

be unmasked through bits in the control registers. Indication of the condition(s) that initiated an interrupt

are readable in the control registers. The polarity of the INT output, as well as selection of a standard or

open drain output, is set through a control register. Once set true, the INT pin goes false only after the

interrupt status registers have been read and the interrupt status bits have returned to zero.

TCBL

15

Transmit Channel Status Block Start (Input/Output) - When operated as output, TCBL is high during

the first sub-frame of a transmitted channel status block, and low at all other times. When operated as

input, driving TCBL high for at least three OMCK clocks will cause the next transmitted sub-frame to be

the start of a channel status block.

U

20

User Data (Input) - May optionally be used to input User data for transmission by the AES3 transmitter,

see

Figure 4

for timing information. If not driven, a 47 k pull-down resistor is recommended for the U

pin. If the U pin is driven by a logic level output, a 100  series resistor is recommended.

TSTN

5

Test In (Input) - This pin is an input used for test purposes. It must be tied to ground for normal operation.

TEST

7

8

10

11

16

17

18

Test Pins - These pins are unused inputs. It is recommended that these pins be tied to a supply (VL or

GND) to minimize leakage current. The CS8406 will operate correctly if these pins are left floating, how-

ever current consumption from VL will increase by 25 A per TEST pin that is left floating.
