Features

Dual T1/E1 Line Interface

Low Power Consumption
(Typically 220mW per Line Interface)

Matched Impedance Transmit Drivers

Common Transmit and Receive Transform-
ers for all Modes

Selectable Jitter Attenuation for Transmit
or Receive Paths

Supports JTAG Boundary Scan

Hardware Mode Derivative of the CS61584

General Description

The CS61583 is a dual line interface for T1/E1 applica-
tions, designed for high-volume cards where low power
and high density are required. Each channel features
individual control and status pins which eliminates the
need for external microprocessor support. The
matched impedance drivers reduce power consumption
and provide substantial return loss to insure superior
T1/E1 pulse quality.

The CS61583 provides JTAG boundary scan to en-
hance system testability and reliability. The CS61583 is
a 5 volt device and is a hardware mode derivative of
the CS61584.

ORDERING INFORMATION

CS61583-IL5: 68-pin PLCC, -40 to +85 °C
CS61583-IQ5: 64-pin TQFP, -40 to +85 °C

JULY ’96

DS172PP5

1

Crystal Semiconductor Corporation
P. O. Box 17847, Austin, Texas, 78760
(512) 445 7222 FAX:(512) 445 7581

Dual T1/E1 Line Interface

TTIP1

TRING1

RRING1

RTIP1

DRIVER

CONTROL

TCLK1

RCLK1

JTAG

4

REFCLK 1XCLK

TV+ TGND RV+ RGND DV+ DGND AV+ AGND BGREF

2

2

2

2

3

2

CLOCK GENERATOR

TPOS1/

TNEG1/

RPOS1/

RNEG1/

LOS1 LOS2

PULSE

SHAPING

CIRCUITRY

CLOCK &

DATA

RECOVERY

LOS

DETECT

TAOS

TTIP2

TRING2

RRING2

RTIP2

DRIVER

TCLK2

RCLK2

TPOS2/

TNEG2/

RPOS2/

RNEG2/

PULSE

SHAPING

CIRCUITRY

CLOCK &

DATA

RECOVERY

TAOS

LOS

DETECT

RESET

CLKE

TAOS1

LLOOP1

RLOOP1

CON01

CON11

CON21

RLOOP2

LLOOP2

TAOS2

CON02

CON12

CON22

AMI2

AMI1

CODER2

CODER1

ATTEN1

ATTEN2

JITTER

ATTENUATOR

E
N
C
O
D
E
R

D
E
C
O
D
E
R

L

O
C

A
L

L

O
O

P
B
A
C
K

R
E

M
O

T
E

L

O
O

P
B
A
C
K

JITTER

ATTENUATOR

E
N
C
O
D
E
R

D
E
C
O
D
E
R

L

O
C

A
L

L

O
O

P
B
A
C
K

R
E

M
O

T
E

L

O
O

P
B
A
C
K

TDATA1

AIS1

RDATA1

BPV1

TDATA2

AIS2

RDATA2

BPV2

RECEIVER

RECEIVER

CS61583

Copyright

Crystal Semiconductor Corporation 1996

(All Rights Reserved)
