5.17 DAC Characteristics

Figure 5-16. DAC Differential Output Test Circuit

Figure 5-17. Maximum Loading

5.17.3

Combined DAC Interpolation and On-chip Analog Filter Response

Parameter

Min

Typ

Max

Unit

Passband (Frequency Response)
to 0.22 dB corner
to –3 dB corner

0
0


0.4125
0.4979

Fs
Fs

Frequency Response 10 Hz–20 kHz –0.02

+0.02

dB

StopBand

0.5465

Fs

StopBand Attenuation

100

dB

Group Delay

10/Fs

s

N output: R

L

= 4.87k + ( [2

F*1800pF]

-1

|| ((2.43k + [2

F*470pF]

-1

) || 4.87k ))

AOUT

AOUT_x+

AOUT_x-

1.96 k

C

L

4700 pF

1200 pF

1.

96

k

22 µF

+

953

4.87 k

2.43 k

-

+

560

+

1800 pF

470 pF

4.87 k

22 µF

P output: R

L

= 1.96k + ( [2

F*4700pF]

-1

|| (1.96k + [2

F*22µF

-

]

-1

) || (953 + [2

F*1200pF ]

-1

))

C

L

10 k

100

50

75

25

2.5

5

10

15

Safe Operating

Region

Cap

a

cit

ive L

oad -- C

(

p

F

)

L

Resistive Load -- R (k

)

L

125

3

20
