CS470xx Data Sheet

Features

Cost-effective, High-performance 32-bit DSP

300,000,000 MAC/S (multiply accumulates per second)

Dual MAC cycles per clock

72-bit accumulators are the highest precision in the

industry

32K x 32-bit SRAM with three 2K blocks assignable to

either Y data or program memory

Integrated DAC and ADC Functionality

8

Channels of 24-bit DAC output: 108dB DR, –98 dB

THD+N

4

Channels of 24-bit ADC input: 105dB DR, –98 dB

THD+N

Integrated 5:1 analog mux feeds one stereo ADC

Configurable Serial Audio Inputs and Outputs

Integrated 192 kHz S/PDIF Rx

Integrated 192 kHz S/PDIF Tx

Supports 32-bit serial data @ 192 kHz

Supports 32-bit audio sample I/O between DSP chips

TDM I/O modes

Supports Different Sample Rates (Fs)

Three integrated hardware SRC blocks

Output can be master or slave

Supports dual-domain Fs on S/PDIF vs. I²S inputs

DSP Tool Set with Private Keys Protect Customer IP

Integrated Clock Manager/PLL

Flexibility to operate from internal PLL, external crystal,

external oscillator

Input Fs Auto Detection w/ µC Acknowledgement

Host Control and Boot via I²C™ or SPI™ Serial Interface

Configurable GPIOs and External Interrupt Input

1.8V Core and a 3.3V I/O that is tolerant to 5V input

Low-power Mode

†”

features differ on CS47024, CS47028, or CS47048.

See

Table 3-1

.

The CS470xx family is a new generation of audio
system-on-a-chip (ASOC) processors targeted at high
fidelity, cost sensitive designs. Derived from the highly
successful CS48500 32-bit fixed-point audio enhancement
processor family, the CS470xx further simplifies system
design and reduces total system cost by integrating the S/
PDIF Rx, S/PDIF Tx, analog inputs, analog outputs, and
SRCs. For example, a hardware SRC can down-sample a
192 kHz S/PDIF stream to a lower Fs to reduce memory
and MIPS requirements for processing. This integration
effectively reduces the chip count from 3 to 1, which allows
smaller, less expensive board designs.

Target applications include:

Automotive head units and outboard amplifiers

Automotive processors and automotive integration hubs

Digital TV

MP3 docking stations

AVR and DVD RX

DSP controlled speakers (subwoofers, sound bars)

The CS470xx is programmed using the simple yet powerful
Cirrus proprietary DSP Composer™ GUI development and
pre-production tuning tool. Processing chains can be
designed using a drag-and-drop interface to place/utilize
functional macro audio DSP primitives and custom audio
filtering blocks. The end result is a software image that is
downloaded to the DSP via serial control port.

The Cirrus Framework™ programming environment offers
Assembly and C language compilers and other software
development tools for porting existing code to the CS470xx
family platform.

The CS470xx is available in a 100-pin LQFP package with
exposed pad for better thermal characteristics. Both
Commercial (0°C to +70°C) and Automotive (–40°C to
+85°C) temperature grades.

Ordering Information:

See

Section 6

for ordering information.

CS470xx
