D-011-0093 37
7. When the Delay Time ( ) icon appears, if desired enter a Delay Time (in minutes)
to be programmed (flashing) by using the INCREASE or DECREASE keys to scroll
to the desired value, and then press the ENTER key. (Refer to Delay Time Entry
Mode icon in Display and Icons for more information about delay function.)
If delay is not desired, set to “0”, press the ENTER key, and proceed.
8. When the icon appears, select ENERGIZE or DE-ENERGIZE by using the
INCREASE or DECREASE keys to toggle to the desired setting, then press the
ENTER key. (Refer to Alarm Output Relay Mode icon in Display and Icons for
more information about relay modes.)
9. At this point, programming for the Zone is complete. The display now shows the
entered limits (if applicable) and settings, along with the current monitored
parameter (if applicable).
10. Repeat steps 1 through 9 for other Zones.
