12 D-011-0093
8
Limit display.
Shows the programmed HIGH limit and LOW limit points where measured con-
ditions exceeding limits will trigger an alarm for the related Zone.
• When programmed for temperature, the limit range allowed is between 299
degree units to –58 degree units.
• When programmed for humidity, the limit range allowed is between 100
RH% units to 0 RH% units.
9
Locked and Unlocked icons.
Indicates EA200 / EA400 lock status.
When EA200 / EA400 is in locked mode, programming cannot be changed; no
configuration modes are accessible.
10
Alarm icon.
When flashing, indicates that a Zone is in an alarm state. When steadily illumi-
nated, indicates that an alarm condition exists, but the programmed time delay
interval has not yet elapsed. When time delay period elapses, the icon will begin
flashing.
11
Delay Time Entry Mode icon.
During programming, indicates selection of delay time mode (up to 120 minutes
delay can be entered). When icon appears, a delay time (in minutes) can be
entered. With a delay programmed for the Zone, conditions exceeding the pro-
grammed limits (such as during a defrost cycle) are ignored for the duration of
the programmed delay.
This function is typically used to prevent false alarms for freezers and coolers
that have defrost cycles or doors that are opened frequently.
Display Icons — continued
Index
No. Icon Function
