14 D-011-0093
14
Temperature Sensor Type display.
During temperature monitoring programming, sensor type (based on conditions
expected for Zone) is entered.
• RED is selected when a “Red” (high-temperature range) sensor is to be used.
• BLUE is selected when a “Blue” (low-temperature range) sensor is to be
used.
Note: See “Accessories” on page 44 for more information regarding sensor
types and appropriate usage.
15
Offset Adjust icon.
Indicates that OFFSET (± 9 units) has been selected (this is selected by press-
ing the OFFSET key).
If desired, offset allows the temperature or humidity reading for the selected
Zone to be offset by a value that aligns the reading displayed on the EA200 /
EA400 with that of existing equipment, thereby correlating the EA200 / EA400
reading with that of existing equipment.
Display Icons — continued
Index
No. Icon Function
