D-011-0093

21

Connecting the EA200 / EA400

Note: Make certain all wiring to be connected is passing through the opening in cen-

ter of mounting plate.

Note: All terminals must be connected to a Class 2 Power Limited Circuit

complying with the National Electric Code NFPA 70, Article 725.

Note: Where required, this equipment is to be isolated from the mains supply by a

limited power source as specified in EN60950.

EA200 / EA400 Connectors
Figure 6 shows and describes the functions of the EA200 / EA400 connectors.

Note: All connections to the EA200 / EA400 circuit board header connectors are

made using Terminal Block Adapters (supplied with the EA200 / EA400 and

with sensors; and available as an accessory item). To ease connection of

stripped wire ends to the adapters, the adapters can be removed from the cir-

cuit board header connectors. Connect stripped wire ends to the adapters as

follows:

Remove the adapter from the circuit board by pulling the adapter up and off

of the circuit board header connector.

Insert stripped wire ends into side of adapter. Secure the connections using

the set screws on the adapter. Check the connection by lightly pulling on

each connection.

After connecting the wire ends to the adapter, align the adapter to the

header pins where connection is desired, and press the adapter fully onto

the header connector pins.
