Winland Electronics WB800 User Manual

Winland Electronics Measuring instruments

Electronic Water Detection Device

D-011-0008 Rev F (08/2012)

PECIFICATIONS

Power Requirement

12/24 VDC 100 mA

12/24 VAC 200 mA

Probe Sensitivity

Will not alarm due to high humidity or condensation.

Operating Temp

32˚ to 130˚F (0˚ to 54˚C); non-condensing environment

Indoor use only.

Output

1 Form C Relay (SPDT)

1 Amp @ 24 VDC, resistive

Buzzer

85dBA @ 10 cm @ 12 VDC, 2.4kHz pulsed (with silence feature)

Probe Options

Includes 4 Standard Supervised Surface Probe (W-S-S)

Accepts up to 8 Supervised (W-S-S or W-UC-S) or up to

16 Unsupervised Probes (W-S-U or W-UC-U)

Probes may be either Surface or Under Carpet

Max Cable Length

500’ (152.4 m) max

Probe Cable

Probes include 15” (4.6 m) cable.

Extend using 22-18 AWG twisted pair.

Console Weight

1 lb (0.45 kg)

Console Dimensions

6.55 x 4.70 x 1” (16.6 x 11.9 x 2.5 cm)

Probe Dimensions

Surface: 2 x 3 x 0.88” (5.1 x 7.6 x 2.2 cm)

Under Carpet: 2 x 3 x 0.18” (5.1 x 7.6 x 0.5 cm)

Mounting

Included standard 3-gang box

Case Material

ABS

Warranty

1 Year Limited

ONTENTS

This package contains:

• 1 WB-800
• 4 Surface Probes - Supervised (W-S-S)
• 1 Standard 3-Gang Metal Mounting Box
• 4 Phillips screws for mounting
• 1 Installation/Operating Instruction Guide

WB-800

DDITIONAL

ROBES

AND

CCESSORIES

W-S-S

WB Surface Probe Supervised

(Up to 8 per WB-800 console)

W-UC-S

WB Undercarpet Probe Supervised

(Up to 8 per WB-800 console)

W-S-U

WB Probe Unsupervised

(Up to 16 per console)

W-UC-U

WB Probe Undercarpet Unsupervised

(Up to 16 per console)

12VDCT

12VDC Transformer Wall Mount Power Supply

BZ-1

Remote Annunciator

Note: Supervised probes are recommended for new WB-800 installations.

ONITORING

THE

ABSENCE

WATER

The WB-800 is not recommended to be used to detect absence of water. The WB-200
is recommended for this type of application.

EAR

IMITED

ARRANTY

Winland Electronics, Inc. (“Winland”) warrants to the end user/purchaser that each product of its manufacture shall
be free from defects in material and factory workmanship for a period of one year from the date of purchase, when
properly installed and operated under normal conditions according to Winland’s instruction.

Winland’s obligation under this warranty is limited to correcting, without charge, at its factory any part or parts
thereof which shall be returned to the factory, by the original purchaser, transportation charges prepaid, within
one year of the date of purchase and which upon examination, shall disclose to Winland’s satisfaction to have been
originally defective. Correction of such defects by repair to, or supplying replacements for, defective parts shall
constitute fulﬁllment of all Winland’s obligations to purchaser under this limited warranty. Repair service performed
by Winland after one year from date of purchase will be for a reasonable service charge.

This limited warranty shall not apply to any of Winland’s products which have been subject to misuse, negligence
or accident or which have been repaired or altered outside of Winland’s factory. The warranty is void if the Product’s
housing or cover is removed.

Winland shall not be liable for loss, damage or expense resulting, directly or indirectly, from the use of its products
or any other cause.

This warranty shall be null and void in its entirety if: (i) the product is altered or modiﬁed in any way that is not
consistent with the manufacturer’s instructions, or (ii) the product is used with or connected to a device: (a) that
such product is not intended to be used with or connected to, (b) is not otherwise consistent with the manufacturer’s
instructions, or (c) is not otherwise approved by the manufacturer.

THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, WITHOUT LIMITATION, ANY
WARRANTIES OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSES, NON-INFRINGEMENT AND TITLE, AND ANY
WARRANTIES ARISING FROM COURSE OF DEALING, USAGE OF TRADE OR OTHERWISE. ALL OTHER REPRESENTATIONS
MADE TO THE END USER/PURCHASER BY ANY OTHER PARTY ARE ALSO EXCLUDED.

WINLAND SHALL NOT BE LIABLE TO ANY PERSON FOR INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES
OF ANY DESCRIPTION, WHETHER ARISING OUT OF WARRANTY OR OTHER CONTRACT, NEGLIGENCE OR OTHER TORT, OR
OTHERWISE. Under no circumstances shall Winland’s liability under this limited warranty exceed the purchase price
paid by the end user/purchaser for the product.

No person, agent or dealer is authorized to give warranties on behalf of Winland nor to assume for Winland any other
liability in connection with any of its products.

RODUCT

AND

CCESSORY

UIDE

EA200-12

EA200-24

EA400-12

EA400-24

EA800

EA800-ip

WB-200

WB-350

WB-800

W-S-S

W-UC-S

W-S-U

W-UC-U

W-S-S (Water Probe, Surface, Supervised) and W-UC-S (Water Probe, Under Carpet, Supervised)

The supervised surface probe can be connected to the EnviroAlert products as well as the WB-800. The alarm will be activated if water is present as well as if the cable is cut.

W-S-U (Water Probe, Surface, Unsupervised) and W-UC-U (Water Probe, Under Carpet, Unsupervised)

The standard surface probe is unsupervised and can be connected to the full line of WaterBug products. No alarm will sound if the cable is cut.

WaterBug® WB-200 (12 or 24 VAC/DC)
6 Zone Unsupervised Water Probe:

Includes 1 unsupervised surface probe (W-S-U)
Accommodates up to 6 probes in parallel
May purchase under carpet probe (W-UC-U)
Will not alarm due to condensation or humidity
Can be used to detect absence of water

WaterBug® WB-350 (9V battery)
6 Zone Unsupervised Water Probe:

Includes 1 unsupervised surface probe (W-S-U)
Accommodates up to 6 probes in parallel
May purchase under carpet probe (W-UC-U)
Will not alarm due to condensation or humidity
Built-in audible alarm with low battery notiﬁcation

EnviroAlert® EA200

Dual Zone Wireless Electronic Monitor:

Temperature, Humidity, Water Presence

EA200-12 (12VDC) and EA200-24 (24VDC)
Has one built-in ambient temperature probe
Connect up to 1 hard wired probe

EnviroAlert® EA400

Four Zone Wireless Electronic Monitor:

Temperature, Humidity, Water Presence

EA400-12 (12VDC) and EA400-24 (24VDC)
Connect up to 4 hard wired probes

EnviroAlert® EA800

Eight Zone Wireless Electronic Monitor:

Temperature, Humidity, Water, Closed Contact, 4-20mA

Connect up to 4 wireless and up to 4 wired probes
Automatic data logging transferable via USB stick

Probe data

Event and alarm history

EnviroAlert® EA800-ip

Eight Zone Wireless Electronic Monitor:

Temperature, Humidity, Water, Closed Contact, 4-20mA

Connect up to 4 wireless and up to 4 wired probes
Remote access via wired IP connection to

Programming and real-time data viewing

Probe data as well as alarm and event logs

Tech Support 8:00am - 5:00pm Central Time

(800) 635-4269 • +1-507-625-7231 P
