5.
Making certain wiring is not pinched or otherwise stressed, re-install the EA200 /
EA400 main chassis onto the mounting plate (installed in Mounting the EA200 /
EA400) as follows:
•
Engage the mating tabs on the EA200 / EA400 main chassis into the
mounting plate upper hinges.
•
Pivot the bottom of the EA200 / EA400 main chassis into closed position
while aligning the retainer tabs on the main chassis with the holes in the rear
mounting plate. Snap the main chassis closed onto the mounting plate.
When properly closed, the main chassis and mounting plate mating surfaces
will be flush. Make certain no wiring is protruding between mating surfaces.
6.
The AUX output can be connected to either a local buzzer or strobe. It can also be
used as a single output to an alarm panel.
