34
5. Lateral adjustment (viewing from the rear)
A. Loosening (by turning counterclockwise) the left hand adjustment bolt and tightening (by turning
clockwise) the right hand adjustment bolt will shift the basket to the left.
B. Loosening (by turning counterclockwise) the right hand adjustment bolt and tightening (by turning
clockwise) the left hand adjustment bolt will shift the basket to the left.
6. Tighten and secure both adjustment bolts and jam nuts.
7. Tighten the bearing box bolts.
8. Replace backguard and re-establish power to dryer.
To Replace The Tumbler and/or Tumbler Support
1. Remove tumbler pulley and bearing box (follow "To Replace The Rear Tumbler Bearing" steps 1
through 4).
2. Remove front panel assembly.
A. Discontinue power to dryer.
B. Disconnect main door switch wiring from inside control wire box.
NOTE: Identify location of each wire for correct re-installation.
C. Open control (service) door.
D. Open lint door.
E. Remove the screws securing the front panel to the dryer.
F. Gently remove front panel assembly from the dryer.
IMPORTANT: When removing front panel assembly be careful not to damage door switch wires.
3. Loosen set screws on rear tumbler bearing.
