American Dryer Corp. ADG-385 User Manual
Page 31
27
To Replace Front Panel
1. Discontinue power to dryer.
2. Disconnect main door switch wiring from inside control wire box.
NOTE: Identify location of each wire for correct reinstallation.
3. Follow procedure for removal of main door assembly.
4. Open control (service) door.
5. Open lint door.
6. Remove the screws securing the front panel to the dryer.
7. Gently remove front panel assembly from dryer.
IMPORTANT: When removing front panel assembly be careful not to damage main door switch
wires disconnected in step 2.
8. Reverse this procedure for installing new front panel.
