22
B. Thermostats and Temperature Sensor
To Replace Hi-Limit Thermostat (330º)
This thermostat is an important safety device serving as an added protection against failure of the air
sail switch to open in the event of motor failure or reduced air flow condition.
IMPORTANT: Under no circumstances should heat circuit safety devices ever be disabled.
1. Discontinue power to dryer.
2. Disconnect wires from hi-limit thermostat.
3. Remove screw, washer, and nut securing
thermostat to the bracket, remove thermostat.
4. Reverse procedure for installing new thermostat.
To Replace DSI Module
1. Discontinue power to the dryer.
2. Remove the wires connected to the terminal strip at the bottom of the module.
3. Remove the soft orange high voltage wire from the module.
4. Remove the two (2) screws securing the module to the plate.
5. Replace module by reversing process.
