26
NOTE: Be careful not to lose the plastic washer on the hinge pin.
5. Re-assemble in the reverse steps.
TO INSTALL NEW MAIN DOOR GLASS
1. Remove main door assembly from dryer (follow main door removal procedure).
2. Lay main door on a flat surface with front of door face down.
3. Remove glass and clean all old sealant off main door. This area must be completely cleaned for
correct bonding.
4. Apply a narrow bead of silicone (ADC P/N: 170730) all around main door area where glass will
rest.
5. Install glass on to door/adhesive and slightly press glass in place.
IMPORTANT: DO NOT press hard or silicone thickness between the glass and door will be
reduced resulting in poor bonding.
6. The door assembly should now be put in an area where it will not be disturbed for at least 24
hours. Depending on the conditions, the curing time of the adhesive is 24 to 36 hours.
7. After 24 hour curing period, install main door on dryer by reversing step 1.
