12 VP-4x1CS - Connecting the VP-4x1CS 4x1 PC Graphics Clean Switcher
6.4.1 Connecting the Ethernet Port Directly to a PC
You can connect the Ethernet port of the VP-4x1CS to the Ethernet port on your
PC via a crossover cable with RJ-45 connectors.
This type of connection is recommended for identification of the factory
default IP Address of the VP-4x1CS during the initial configuration
After connecting the Ethernet port, configure your PC as follows:
1. On your desktop, right-click the My Network Places icon.
2. Select Properties.
3. Right-click Local Area Connection Properties.
4. Select Properties.
The Local Area Connection Properties window appears.
5. Select the Internet Protocol (TCP/IP) and click the Properties Button (see
Figure 7 ).
Figure 7: Local Area Connection Properties Window
