18
From this screen you will also be able to assign
Users to the station by tapping [Setting User].
Figure 4 2 : User Setup
Enter the desired User Name and password and
tap [Apply]. The User will now be available in the
User dropdown.
6. [Alarm Configuration]
This screen allows you to select various alarm
types from the drop down menu, and fill in the
required settings for each alarm.
Default settings (standard factory settings) can
be found in Appendix D.
Figure 43: Alarm Configuration
ENERGY
The [ENERGY] tab will take you to the Power usage
detail screen. From here you will be able to see the
totalized values for Flow and KWh in tabular format.
Figure 4 4 : Energy Home Screen
By tapping on the desired box a tabular screen will
appear as shown in Figure 45.
Figure 4 5 : Flow Totals Overview
Tap [Next] to successively view the totals for each
day, week, month and year. Use the scroll bar to
move up and down or left and right.
