Parts Listings and Cross-Sectionals
Item Part name Material
122A Stationary shaft Standard: silicon carbide
Optional: Dry-guard silicon carbide
122B Drive shaft Steel
141C Clamp ring Ductile iron
157A Bearing spacer – radial bearings Teflon
178S 1 Key – impeller to radial bearings Teflon
178Y Key – drive carrier Steel
197B 1 Bearing – radial Standard: silicon carbide
Optional: Dry-guard silicon carbide
197C 1 Bearing – reverse thrust Carbon-filled Teflon
197D 1 Bearing – impeller thrust Standard: carbon-filled Teflon
Optional: silicon carbide
Optional: Dry-guard silicon carbide
228 Frame – bearing Cast iron
332A 1 Labyrinth seal – outboard Brass
333D 1 Oil lip seal – inboard Buna rubber
351G 1 Gasket – casing drain Gylon
355A 1 Hex nut Steel
356A Hex capscrew – clamp ring to casing 304 SS
358 Flange – casing drain Steel
360A 1 Gasket – end cover to frame Varnished Kraft
360W Gasket – frame to clamp ring Aramid fibers with EPDM
370B Hex capscrew – frame to clamp ring 304 SS
370C Hex capscrew – end cover 304 SS
412M 1 O-ring – containment shell Standard: Viton
Optional: EPDM
Optional: Teflon-encapsulated Viton
Optional: Chemraz 505
Optional: Kalrez 4079
426A Hex capscrew – casing drain 304 SS
740B Drive magnet assembly Cast iron / neodymium iron
750 Containment shell Tefzel / fiber-reinforced vinylester
1 Recommended spare parts
