American Electric Lighting a division of Acuity Lighting Group, Inc. Conyers, GA
DRAWING NO. B62403 REV H (BACK) ©2003 ACUITY LIGHTING GROUP, INC. PART NUMBER 059-71-64056
SERIES 153
FLAT LENS MODEL
SERIES 53
REFRACTOR MODEL
The optical assembly should be cleaned with a mild detergent
and rinsed well with clean water to maintain the efficiency
of the luminaire. See the instruction under LAMP INSTALLATION
AND SERVICE to open the bezel.
To remove the refractor, push back on the spring steel retainers
to disengaged them from the refractor and then lift the refractor
out of the bezel. To replace it, orient the "street side" of the
refractor so it is adjacent to the latch, insert it into the bezel
To remove the lens, depress the two spring slide clips and remove
lens. To replace, slide lens under rear retainer and push down.
The spring side clips will snap over glass and retain it.
To remove the lens, rotate clips riveted to side of bezel 180ù.
Then push back on the spring steel retainer located at the hinge
side of bezel, push lens up and slide out. To replace it, orient
the lens so the masked side will be inside, and the flat portion
of masked lens will be next to latch side of bezel after it is
slid in place. Rotate side clip back in place.
MAINTENANCE AND CLEANING REFLECTOR (BOTH MODELS)
The reflector can be removed by loosening the
two captive screws, which hold it up inside of the
the housing. However, the socket electrical connector
located inside of the ballast compartment should be
disconnected first. Reverse this procedure to replace
the reflector.
To remove the bezel, position it so that it is only
partially open and then disengage it from the hinge
hooks.
NOTE: In luminaire with the OPTIONAL HINGE KEEPER
feature, the hinge keepers will have to be slid
sideways to the left (facing to the rear). "Unlock"
the hinges, to allow the hinges to be engaged or
disengaged. After engaging the hinges, the hinge
keepers should be slide over to the right (facing
to the rear) to the "locked" position to assure
that the hinges will remain engaged.
Loosen the receptacle clamping screw, rotate the
receptacle and twist it clockwise until it locks
into position.
OPTIONAL PHOTOCONTROL
This fixture is not designed for use with S55SD-150 or S56SE-150 lamps.
Use of these lamps can result in mechanical damage to the fixture.
CAUTION
!
