Part No. 5375-901, Rev E.1
MaxiProx
®
Installation Guide
Page 8 of 19
March 2012
© 2008 - 2012 HID Global Corporation. All rights reserved.
Table 5: Switch Description - SW2
Switch
Default
Description
1. Serial Baud 3 control
On
See Table 7: Baud Rate Chart – RS232 and RS422
2. Note address 0
N/A
Unused
3. Note address 1
N/A
Unused
4. Note address 2
N/A
Unused
5. Note address 3
N/A
Unused
6. Note address 4
N/A
Unused
7. Unused
8. Unused
Table 6: Mode Chart
Mode
SW1-1
SW1-2
SW1-3
SW5-3
SW5-4
SW5-5
P3 & P4
Jumpers
Wiegand
ON
ON
ON
NA
NA
NA
1-2
Clock-and-Data
OFF
ON
ON
NA
NA
NA
1-2
RS232
ON
OFF
ON
NA
OFF
OFF
2-3
RS422
terminated
OFF
OFF
ON
ON
OFF
OFF
2-3
RS422 unterm.
OFF
OFF
ON
OFF
OFF
OFF
2-3
Table 7: Baud Rate Chart – RS232 and RS422
BAUD
SW1-7
SW1-8
SW2-1
9600
ON
ON
ON
4800
OFF
ON
ON
2400
ON
OFF
ON
1200
OFF
OFF
ON
Table 8: Switch Description - SW5
Switch
Default
Description
1. Data Isolation 1
On
See 1 below
2. Data Isolation 0
On
See 1 below
3. RS422 Terminating Resistor
On
See 5 below
4. Serial Hardware line setting 1
Off
See 6 below
5. Serial Hardware line setting 2
Off
See 7 below
1. Open Collector Data Outputs SW5-1&2 when using Wiegand or Clock & Data Interface.
Configure the data outputs so the MaxiProx is electrically isolated from the Host pull-up resistors.
The default (standard) configuration is non-isolated outputs; switches SW5-1 & 2 are ON.
Note: When configuring the outputs as isolated, use separate power supplies for the MaxiProx and
Host. These switches are unused when in RS232 or RS422 mode.
