Part No. 5375-901, Rev E.1 MaxiProx
®
Installation Guide
Page 12 of 19 March 2012
© 2008 - 2012 HID Global Corporation. All rights reserved.
HIGH VOLTAGE
- CAUTION -
TB1-1 +DC
TB1-2 SHIELD
TB1-3 GROUND
TB1-4 TAMPER COMMON
TB1-5 TAMPER SELECT
TB2-1 DATA0/DATA/TD/RX+
TB2-2 DATA 1/CLK/RD/RX-
TB2-3 DATA RTN
TB2-4 GREEN LED
TB2-5 RED LED
TB2-6 BEEPER
TB2-7 HOLD/CARD PRESENT
TB2-9
TX+ TB2-8
TX-
1 3
P2
5
1
TB1
9
1
TB2
P1
1 3
P4
3
1 1
3
P3
SHUNT PINS 2 AND 3+21-28.5 VDC (DEFAULT)
SHUNT PINS 1 AND 2+11-20 VDC
SW1 SW2 SW5
SW5-1
SW5-2
SW5-3
SW5-4
SW5-5
SW5-6
SW5-7
SW5-8 DATA 1 ISOLATION
DATA 0 ISOLATION
RS422 TERM RESISTOR
RS 232/422 LINE 1
RS 232/422 LINE 2
NOT USED
NOT USED
NOT USED SW2-1
SW2-2
SW2-3
SW2-4
SW2-5
SW2-6
SW2-7
SW2-8 SERIAL BAUD 3
NODE ADDRESS 0
NODE ADDRESS 1
NODE ADDRESS 2
NODE ADDRESS 3
NODE ADDRESS 4
NOT USED
NOT USED SW1-1
SW1-2
SW1-3
SW1-4
SW1-5
SW1-6
SW1-7
SW1-8 INTF. MODE 1
INTF. MODE 2
INTF. MODE 3
BEEPER
LED FLASH
LED MODE
SERIAL BAUD 1
SERIAL BAUD 2
1 8 1 8 1 8
1.64
2.625
4.000
2.625
4.000
1.64
4.000 4.000
- CAUTION -
Figure 2: MaxiProx interior view showing mounting hole locations
