EDGE EVO Hi-O Networked Controller

EH400

82000-920 C.0

INSTALLATION GUIDE

8

©2009 - 2011 HID Global Corporation. All rights reserved.

Contact

5

5.1 Direct Connect

If connecting EDGE EVO to a network using static IP addressing or if the Discovery GUI is not installed on the PC, use this

method.

Note: The computer must be running Windows 2000 or XP and be configured for DHCP.

1. Disconnect the computer from the network and directly connect EDGE EVO to the computer with an Ethernet cable.
2. Click

Start > Run. Enter ipconfig /renew

3. Access a web browser and enter

169.254.242.121 into the Address field

5.2 OPIN Discovery/Update Application

Use the

OPIN Discovery / Update Application on a computer to locate, connect and update EDGE EVO.

System Requirements: Java 6.0 or later. Go to

www.java.com

to download.

Operating Systems:

Windows XP and Fedora 8.

Find the OPIN Discovery / Update Application at

www.ShareMethods.com

>

OPIN > Firmware > 2.3.x. Save the files to your

local harddrive.
The EDGE EVO must be connected to the network, and power applied, before the device is discovered.

1. With a computer connected to the same network as EDGE EVO, double-click

opin-update.jar

. The OPIN Discovery / Update

Application opens and the

Controller Table populates.

Note: If the Controller Table does not populate, go to Edit > Broadcast Address. The default broadcast address is

255.255.255.255. Some network switches may block this transmission. If this is the case, change the subnet to match

the network, for example 10.7.255.255. Click

Save.

2. Select the desired device from the list.
3. From

Path to Update Package frame, browse to the firmware location on the computer.

4. Click

Install. Firmware is installed.

EH400 - Provides additional functionality to not only Install firmware, but to Changeover, and Rollback firmware

updates. Once firmware is installed, click

Changeover to switch to the updated firmware. Click Rollback to switch

back to the previous firmware version.

5. View the

Status Log for each status while performing Discovery and Update functions.
