Swiftech H20KITS User Manual
Page 10
10
7.5
00"
4.750"
4.125"
RA
DIA
TOR
MO
UT
IN
G H
O
LE
S
Diameter
4 places
4.125"
0.6
35"
4.5
00"
FAN MOUNTING HOLES
0.125“
Diameter
8 places
0.180“
Copyright
swiftech 2002
1:1 scale
WARNING: if you are downloading this
page from the Internet, make sure your
printer is setup properly and does not scale
the image down! Measure the dimensions
before you drill holes in your case !
