Appendix C
DC Terminal Block Wiring
Instructions
This appendix contains instructions on how to connect the AT-D8224XL
switch to a DC
power source. The instructions describe how to
connect the DC terminal block on the rear panel of the LAN equipment
to a 36 - 60 V DC power source.
Reviewing Safety Precautions
Please review the following safety precautions before you begin to
connect the LAN equipment to a DC power source.
Warning
For centralized DC power connection, install only in a restricted
access area.
" 16
Note
A tray cable is required to connect the power source if the unit is
powered by centralized DC power. The tray cable must be UL listed
Type TC tray cable and rated at 600 V and 90 degree C, with three
conductors, minimum 14 AWG.
" 17
Warning
Only trained and qualified personnel are allowed to install or
replace this equipment.
