AT-8216FXL, AT-8224XL, and AT-8288XL Series Installation Guide
23
RS232 Connector
The RS232, DB-9 female connector on the front panel of the switch is
used to establish an out-of-band local management session with the
switch and the AT-S24 management session. Establishing a local session
requires a terminal or a personal computer with a terminal emulator
program. The terminal is connected to the RS-232 port with a straight-
through cable.
Reset Button
This button resets the switch. It is primarily used for diagnostics or
resetting the switch statistics stored by the management software,
Omega. You can also reset the switch using the Omega management
software, as explained in the AT-S24 Management Software User’s
Guide.
System LEDs
The switch’s system LEDs are Power, and Fault. They indicate the over-all
operating status of the switch.
More details about the LEDs, refer to Table 3, Switch System LED
Status, on page 41.
AC Power
Connector
The switch has a single AC power supply socket on the back panel,
which has autoswitch AC inputs. The input voltage range is from
100-120/200-240 VAC, 4/2A, 50/60 Hz. The power cord acts as an ON/
OFF switch.
Note
The AT-D8224XL switch has a DC power terminal block on the back
panel.
