AT-8216FXL, AT-8224XL, and AT-8288XL Series Installation Guide
25
Network Topologies
The following sections contain two examples of network configurations
that use the switch models described in this guide.
Standalone
Configuration
Figure 9 shows the AT-8224XL used as a standalone switch for a group
of heavy traffic users. Switching on the desktop is either through a single
end-station per switch port or through a multi-port hub. A 100 Mbps
server is connected to a port, providing end stations high-speed access
to its applications.
Figure 9 AT-8224XL Switch in a Standalone Configuration
10BASE-T/100BASE-TX NETWORK PORTS
POWER
4X 5X 6X 7X 8X 9X 1 2X 3X
STATUS
RESET
FAULT RPS PWR
10BASE-T / 100BASE-TX
FAST ETHERNET SWITCH
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
10BASE-T / 100BASE-TX 1X 3X 5X 7X
2X 4X 6X 8X
9X 11X 13X 15X
10X 12X 14X 16X
17X 19X 21X 23X
18X 20X 22X 24X
A
B
RS-232 TERMINAL PORT 100M LINK / ACTIVITY 10M LINK / ACTIVITY HALF DUP/ COL FULL DUP PORT ACTIVITY L /A
L /A
D/C
D/C L /A D/C
AT-8224XL
Hub
Legend
Shared 10/100 Mbps link
Dedicated 10 Mbps link
Dedicated 100 Mbps link
10/100 Mpbs link
