AT-8216FXL, AT-8224XL, and AT-8288XL Series Installation Guide
37
Caution
Air vents must not be blocked and must have free access to the
room ambient air for cooling.
"
13
6. Mount the switch in the rack using standard screws (not provided).
7. Apply AC power to the switch by plugging the power cord into the AC
power connector on the back panel of the unit (shown in Figure 11)
and plugging the other end into a power outlet.
Warning
The power cord is used as a disconnection device. To de-energize
equipment, disconnect the power cord.
"10
Note
If you purchased an AT-D8224XL switch, refer to Appendix C for
instructions on connecting the switch to a DC power source.
As power is applied to the switch, the Fault LED (shown in Figure
12) flashes as the switch runs a series of internal self tests. After the
switch has finished running its self tests, the Fault LED will stop
flashing and will remain OFF. Refer to the section ‘Switch LEDs’
on page 41 for information on all of the system and port LEDs.
8. Connect the data cables, making sure each connection has a good
valid link and that the switch is receiving packets. For 10/100Base-TX
ports, use a straight-through cable to connect to workstations and
servers, or use a crossover cable to connect to hubs, routers, or other
switches. See Table 2, Switch Cabling Specifications, on page 33 for
cable specifications.
9. Go to the procedure ‘Setting Up a Terminal for Local Management’
on page 40 to access the Omega management interface on the
switch.
