Virtual LAN Commands
10-8
get-svlan-tbl
This command shows the table of defined Virtual LANs.
get-svlan-tbl {run|nvram}
SYS_console>get-svlan-tbl run
RUNTIME SECURITY VIRTUAL LANs TABLE
===========================================
0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1
SVLAN - 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6
1 : + + + + + + + + - - - - - - - -
2 : - - - - - - - - + + - - - - - -
SYS_console>
The default SVLAN is ports 11, 12, 13, 14, 15, and 16 (groups F, g, and
H. It is not displayed by the
“get-svlan-tbl” command. SVLAN
1 is ports 1, 2, 3, 4, 5, 6, 7, and 8 (groups A, B, C, and D). SVLAN 2 is
ports 9, 10, (group E).
Note
If you assign ports to multiple SVLANs, they become one SVLAN and
includes all the original VLAN ports.
You can view the SVLANs settings by entering the CLI “ get-svlan-
matrix ” command, which shows the connectivity matrix of all the
ports (identifies ports transmitting and ports receiving).
