AT-8116 User’s Guide
10-5
Note
All ports not defined as a member of a VBC are members of the
default VBC.
get-vbc-matrix
Retrieve the current broadcast domain matrix for the switch. Here
only the broadcast address will be affected.
The first column is the source port list. The other columns are
broadcast destination ports. If a “+” is in the matrix matching up the
source port to the destination port, frames can be forwarded
between these ports. If a “-” is in the matrix matching up the source
port to the destination port, no frames can be forwarded between
the ports.
SYS_console>get-vbc-matrix
VBC CONNECTIVITY MATRIX
===========================================
0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1
SRC to : 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6
1 : - + + + - - - - - - - - - - - -
2 : + - + + - - - - - - - - - - - -
3 : + + - + - - - - - - - - - - - -
4 : + + - - - - - - - - - - - - - -
5 : - - - - - + + + + + + + + + + +
6 : - - - - + - + + + + + + + + + +
7 : - - - - + + - + + + + + + + + +
8 : - - - - + + + - + + + + + + + +
9 : - - - - + + + + - + + + + + + +
10 : - - - - + + + + + - + + + + + +
11 : - - - - + + + + + + - + + + + +
12 : - - - - + + + + + + + - + + + +
13 : - - - - + + + + + + + + - + + +
14 : - - - - + + + + + + + + + - + +
15 : - - - - + + + + + + + + + + - +
16 : - - - - + + + + + + + + + + + -
SYS_console>
