AT-9400 Series Gigabit Ethernet Switches Installation Guide

51

Pin Connections for the 10/100/1000 Ethernet Interface

The following figure illustrates the pin allocation for the RJ-45 10/100/1000
Ethernet connectors.

Figure 1:

RJ-45 Pin Allocation

8

8

1

1
