Appendix A: Technical Specifications
50
Power Specifications
Power Supply for Non-POE model
100-240VAC/50-60 Hz universal input
Total Power Consumption
ˆ AT-8000GS/24 — 100-240 VAC, 1.0 A, 50/60 Hz, 65W max
ˆ AT-8000GS/48 — 100-240 VAC, 1.5 A, 50/60 Hz, 125W max
ˆ AT-8000GS/24POE — 100-240 VAC, 3.5A, 50/60 Hz, 185W max
POE Output Power
ˆ Available POE Power — 140 W Max@ 48 VDC
ˆ IEEE 802.3af Class 3 (15.4 W) — Max 9 ports
ˆ IEEE 802.3af Class 2 (7.3 W) — Max 18 ports
Certifications
EMI (Emissions): FCC Class A, EN55022 Class A,
EN61000-3-2, EN61000-3-3, VCCI Class
A, C-TICK, CE
EMC (Immunity): EN55024
Electrical and Laser Safety: EN60950 (TUV), UL 60950 (
C
UL
US
)
EN60825
Quality and Reliability for AT-9424T:
MTBF > 170,000 hrs.
Quality and Reliability for all other AT-9400 Series Switches:
MTBF > 100,000 hrs.
Compliance Marks: CE,
C
UL
US
, TUV, C-Tick
Cable, Port, and Pinout Information
This section describes the devices physical interfaces and provides
information about cable connections. Stations are connected to the device
ports through the physical interface ports on the front panel. For each
station, the appropriate mode (Half/Full Duplex, Auto) is set.
