AT-8000GS Series Gigabit Ethernet Switch Installation Guide
15
Port Descriptions
10/100/1000 Base-
T Gigabit
Ethernet Ports
The 10/100/1000Base-T Gigabit ports are RJ-45 ethernet connectors. The
10/100/1000 Mbps ports support half- and full-duplex mode.
SFP Port
Small Form Factor Pluggable (SFP) Optical Transceivers are integrated
duplex data links for bi-directional communication over optical fiber,
designed for high-speed Fiber Channel data links. The SFP port is
designated as 100Base-FX or 1000Base-LX/SX.
Table 1 lists the supported SFPs:
RJ-45 Console
Port
The RJ-45 port on the rear panel is an asynchronous serial console port
supporting the RS-232 electrical specification. The port is used to connect
the device to a console managing the device. This interface configuration
is as follows:
ˆ Eight data bits.
ˆ One stop bit.
ˆ No parity.
ˆ Baud rate is 115,200 (default). The user can change the rate from
115,200 down to 2400 bps.
Table 1 SFP Support
Allied Telesis
Reference
Vendors and Parts
AT-SPSX 500m 850nm 1000Base-SX Small Form Pluggable -
Hot Swappable
AT-SPLX10 10km 1310nm 1000Base-LX Small Form Pluggable
- Hot Swappable
AT-SPLX40 40km 1310nm 1000Base-LX Small Form Pluggable
- Hot Swappable
AT-SPZX80 80km 1550nm 1000Base-ZX Small Form Pluggable
- Hot Swappable
AT-SPBD10-13 10km Bi-Directional GbE SMF SFP 1310Tx/1490Rx
- Hot Swappable
AT-SPBD10-14 10km Bi-Directional GbE SMF SFP 1490Tx/1310Rx
- Hot Swappable
