Page 65
AT-x210-9GT, AT-x210-16GT, and AT-x210-24GT Switches Installation Guide
55
Table 15 lists the RJ-45 connector pins and their signals when a
1000Base-TX port is operating at 1000 Mbps.
Table 15. RJ-45 1000Base-T Connector Pinouts
Pin
Pair
Signal
1
1
TX and RX+
2
1
TX and RX-
3
2
TX and RX+
4
3
TX and RX+
5
3
TX and RX-
6
2
TX and RX-
7
4
TX and RX+
8
4
TX and RX-
