Chapter 2: Installation
28
Installing the Switch in an Equipment Rack
Note: These instructions show you how to install an AT-x210-9GT,
AT-x210-16GT or AT-x210-24GT switch in an equipment rack. Rack
mount kit brackets are included with AT-x210-16GT and AT-x210-24GT
switches. The AT-x210-9GT switch is installed in a rack with the optional
AT-x210-9GT rack mount kit (Part Number 990-003904-00).
To install AT-x210-9GT, AT-x210-16GT or AT-x210-24GT switches in a
19-inch equipment rack, follow these steps:
1. Place the unit upside down on a level, secure surface.
Figure 15. Turning the Switch Upside Down
2. Unscrew the rubber feet from the bottom and turn the switch over.
3. For AT-x210-24GT Switches, attach two rack mount brackets to the
sides of the switch using the bracket screws that come with the unit.
Figure 16. Attaching brackets to an AT-x210-24GT
1971
