Chapter 6: Powering On the Switch

94

Powering On the Switch

Before powering on the switch, refer to “Power Specifications” on
page 112 for the power specifications.To install the power cord retaining
clip and power on the switch, perform the following procedure:

1. To install the power cord retaining clip, position it with the “u” part

facing down, press in the sides, and insert the ends of the clip into the
holes in the retaining bracket on the AC connector. Refer to Figure 45.

Figure 45. Installing the Retaining Clip

2. Raise the retaining clip. Refer to Figure 46 on page 95.
