x310 Series Installation Guide for Stand-alone Switches

21

The back panel of the AT-x310-26FT Switch is shown in Figure 3.

Figure 3. Back Panel of the AT-x310-26FT Switches

The back panel of the AT-x310-26FP and AT-x310-50FP Switches is
shown in Figure 4.

Figure 4. Back Panel of the AT-x310-26FP and AT-x310-50FP Switches

The back panel of the AT-x310-50FT Switch is shown in Figure 5.

Figure 5. Back Panel of the AT-x310-50FT Switch

AC Power
Connector

AC Power Connector

AC Power Connector
