Front and back panels – Allied Telesis x310 Series User Manual
Page 19
x310 Series Installation Guide for Stand-alone Switches
19
Front and Back Panels
The front panels of the x310 Series switches are shown in Figure 1 here
and Figure 2 on page 20.
Figure 1. Front Panels of the AT-x310-26FT and AT-x310-26FP Switches
10/100Base-TX Ports
10/100/1000Base-T Ports
SFP Slots
Stacking Slots
Management Panel
AT-x310-26FT
10/100Base-TX Ports with PoE
10/100/1000Base-T Ports
SFP Slots
Stacking Slots
Management Panel
AT-x310-26FP
