AT-WA1004G User’s Guide
95
Also, note that the terms “Incoming” and “Outgoing” on this screen refer
to traffic from the client (PC) viewpoint.
Figure 29 Special Applications Screen
Data - Special Applications Screen
Checkbox Use this to Enable or Disable this Special Application
as required.
Name Enter a descriptive name to identify this Special
Application.
Incoming Ports ❏ Type - Select the protocol (TCP or UDP) used when
you receive data from the special application or
service. (Note: Some applications use different
protocols for outgoing and incoming data).
❏ Start - Enter the beginning of the range of port
numbers used by the application server, for data
you receive. If the application uses a single port
number, enter it in both the “Start” and “Finish”
fields.
❏ Finish - Enter the end of the range of port numbers
used by the application server, for data you
receive.
