Lan screen – Allied Telesis AT-WA1004G User Manual
Page 37
AT-WA1004G User’s Guide
37
LAN Screen
Use the LAN link on the main menu to reach the LAN screen An example
screen is shown below.
Figure 7 LAN Screen
Data - LAN Screen
TCP/IP
IP Address
IP address for the Wireless Router, as seen from the
local LAN. Use the default value unless the address is
already in use or your LAN is using a different IP
address range. In the latter case, enter an unused IP
Address from within the range used by your LAN.
Subnet Mask
The default value 255.255.255.0 is standard for small
(class “C”) networks. For other networks, use the
Subnet Mask for the LAN segment to which the
Wireless Router is attached (the same value as the
PCs on that LAN segment).
