AT-WA1004G User’s Guide
69
Connection Status - PPPoE
If using PPPoE (PPP over Ethernet), a screen will be displayed when the
“Connection Details” button is clicked.
Data - PPPoE Screen
Connection
Physical Address The hardware address of this device, as seen
by remote devices on the Internet. (This is
different to the hardware address seen by
devices on the local LAN.)
IP Address The IP Address of this device, as seen by
Internet users. This address is allocated by
your ISP (Internet Service Provider).
Subnet Mask The Subnet Mask associated with the IP
Address above.
PPPoE Link Status
❏ This indicates whether or not the
connection is currently established.
❏ If the connection does not exist, the
“Connect” button can be used to
establish a connection.
❏ If the connection currently exists, the
“Disconnect” button can be used to break
the connection.
Connection Log
Connection Log
❏ The Connection Log shows status
messages relating to the existing
connection.
❏ The most common messages are listed in
the table below.
❏ The “Clear Log” button will restart the
Log, while the Refresh button will update
the messages shown on screen.
Buttons
Connect If not connected, establish a connection to
your ISP.
