PC208 INTRODUCTION
5
WINDOW BASICS
Close Box
Used to close the current window usually with
out saving changes (if applicable). To use a
mouse, click on the box. To use keyboard,
press ESC, or select CANCEL button if
available. Select FILE | CLOSE to close the
main file in EDLOG.
Scroll Bars
Used to scroll displayed information. To use
mouse, click on arrow (triangle) at either end to
scroll in that direction. Click on the bar between
the arrows to move in larger steps. To scroll
with the keyboard, cursor keys, PAGE UP, and
PAGE DOWN key are normally used.
Zoom Box
Used to change the size of the displayed
window. Toggles between full size and current
size. To use mouse, click on box. To use
keyboard, press F5 key in PC208E. With
EDLOG use WINDOW main menu options to
alter size.
Resize Corner
Used to size the window. To use with mouse,
click and drag corner to desired size. See
Zoom Box for keyboard controls.
Close Box
Zoom Box
Title Bar
Scroll Bar
Scroll Bar
Resize Corner
