OBS500 Smart Turbidity Meter with ClearSensor™ Technology
Diameter: 4.76 cm (1.875 in)
Length: 27 cm (10.625 in)
Weight: 0.52 kg (1.15 lb)
Maximum Cable Length: 460 m (1500 ft) (1 channel SDI-12 or
Analog); 15 m (50 ft) (RS-232)
7. Installation
If you are programming your datalogger with Short Cut, skip Section 7.3,
Datalogger/RTU Connection, and Section 7.6, Programming. Short Cut does
this work for you. See Section 4, Quickstart, for a Short Cut tutorial.
7.1 Default Settings
The OBS500 is configured at the factory with the default settings shown in
TABLE 7-1. For most applications, the default settings are used.
TABLE 7-1. Factory Settings
SDI-12/Analog SDI-12
SDI-12 Address 0
RS-232 Baud Rate 9600
Turbidity units TU
Temperature units Celsius
7.2 Device Configuration Utility
The Device Configuration Utility is used to change settings, set up the analog
sensor, enter RS-232 commands, and update the operating system.
Use the OBS500 test cable to connect the OBS500 to a computer running
Device Configuration Utility. The red wire is connected to a 12 Vdc power
supply and the black to ground. The datalogger power supply is a good choice
to use for the power supply. Device Configuration Utility software is shipped
on the Campbell Scientific ResourceDVD included with the OBS500.
The OBS500 is supported in our Device Configuration Utility
version 1.16 or higher.
NOTE
13
