Section 7. Camera Operation Using Web Browser Interface
7-26
Always On
• The Deep Sleep power consumption(6mA typical) is not affected by
the Ethernet Power Mode
• Ethernet, RS-232 and RS-485 communications are non responsive
in the Deep Sleep State.
Moderate Power Save
Mode
• Not recommended
Deep Sleep
Full Power Save Mode
• The Deep Sleep power consumption(6mA typical) is not affected by
the Ethernet Power Mode
• If Ethernet communications are not used this can reduce the power
consumption of the camera by 50 mA when the camera exits the
deep sleep state.
Always On
• The Off State power consumption(1mA typical) is not affected by
the Ethernet Power Mode
• Ethernet, RS-232 and RS-485 communications are non responsive
in the OFF State.
Moderate Power Save
Mode
• Not recommended
Off State
Full Power Save Mode
• The Off State power consumption(1mA typical) is not affected by
the Ethernet Power Mode
• If Ethernet communications are not used this can reduce the power
consumption of the camera by 50 mA when the camera exits the
deep sleep state.
See the Section 7.2.2 Ethernet Power Mode Settings for other
settings that influence the power consumption.
TABLE 7-5. Capture Response Times
Power Mode Typical Capture Time from
Trigger Event
Fully On <1 Second
Partially On 10 Seconds
Deep Sleep 15 Seconds
Off State 90 Seconds
