Section 23. Quick Notes
23-3
TABLE 23-1. Power Mode Summary
Power Mode Ethernet
Power Save
Mode
Quiescent
Current Draw
Max.@12VDC
Time (Seconds)
From wakeup to
start of capture
Time (Seconds)
In Fully On Mode
(Active Current Draw)
Always On 250mA < 1 Second 0 – Always Active
Fully On Full Power
Save Mode
200mA < 1 Second 0 – Always Active
Always On 80mA 10 Seconds 20 Seconds
Partially On Full Power
Save Mode
10mA 10 Seconds 20 Seconds
Always On 6mA 15 Seconds 25 Seconds
Deep Sleep Full Power
Save Mode
6mA 15 Seconds 25 Seconds
Always On 1mA 90 Seconds 120 Seconds
Off State Full Power
Save Mode
1mA 90 Seconds 120 Seconds
3. Set the details of the still image or video
a. Set the Still Image Settings
b. Set the Video Settings
4. Set other details related to Communications and I/O
These other parameters are located under
a. Network
b. System
c. Communications
