Flytec
5030 GPS
Airspeed Offset This value will be added or subtracted to
the actual speed value. This value can be
used to compensate the slower airsflow
under the airfoil 0
Vario audio threshold Fine tuning of climbing tone max 20 cm 2 cm/sec
Pilot name Pilot name entry; max 25 letters not set
Speed mode TAS or IAS; upper or lower range 1.4; 5.3 0 = true airsp.
Units Meter or feet; Km/h or mph or knots
Temp.: In Grd C or Grd F; Km or miles m ; km/h ;
Grd C; Km
Init EEPROM Back to factory settings 3.1 No
Erase all records Deletion of flight memory (all records) This
command formats the flight memory if an
error in the memory occurred. The settings
remain unchanged 3.2 no
Erase all WP& routes Deletion of all WPs and Routes 3.3; 3.4 no
Init GPS Entry of posit. for faster satellite reception
Set of a geodetic map system 2.1
2.6; 6.2 actual position
1 = WGS84
Coordinate Format * dd°mm,mmm or dd,ddddd or dd°mm'ss”
UTM ; Suisse Grid #
dd,mm,mmm
Recording mode Autom. or manual flight recording 3.2 Aut.
Average thermal
climb Time delay for average climb in the
thermals 1.10 0,5…10 min
10min
Glider type Name of glider for OLC not set
Glider ID Glider registration for OLC not set
McCready
Tone gap Delay for McCready acc. to climb
Acoustic dead band in +/- xx cm/sec 1.9 7 seconds
30 cm/sec
Vario Display Circle scale or bar scale 1.1 Yes = circle
Userfields 3 user selectable pages with 6 normal or 4
large fields 1.7 Yes = 6 fields
Init CTRs Memory Reorganisation 2.11
Note: It can take some seconds to delete the WPs, routes or flights. Please wait until the
process is completed and the confirmation “yes” resets to “no”.
* the highest accuracy is achieved when using the same co-ordinate format as most of
the GPS modules do. This is: dd°mm,mmm ( degrees; minutes and decimals of minutes
). With all other formats rounding errors can occur. ( up to 15m )
3.2 Flight Memory and Flight Analysis
In contrast to previous flight instruments the recording mode does not need to be specially
activated as each flight is automatically saved.
The flight logging system used in the Flytec 5030 GPS registers not only the flight altitude
and speed, but also logs, with the GPS receiver switched on, the time, position of the pilot in
the WGS84 coordinate system, the GPS altitude and flight speed (= air speed).
The value set in the Basic Settings/ record interval determines the time interval in seconds
after a new data record is written in the Flytec 5030 GPS's memory.
A scan rate of 2 second is advisable for tests or aerobatic flights. The factory setting is 10
seconds. In order that such a flight is logged in the flight memory, it has to be at least 3
minutes long . For the beginning of a flight the following rule applies:
The start is recognized as soon as the groundspeed reaches at least 10 km/h or if the
instrument recognizes an altitude difference of at least 30m. In each case however, the
31/53
