2
SPECIFICATIONS (Cont’d)
7. RATE ACCURACY AND REPEATABILITY: +0.025%
8. RATE MINIMUM INPUT FREQUENCY: 0.03 Hz
Note: At frequencies below 0.03 Hz (1 pulse every 32 sec.) the rate indicator
will display a zero.
9. RATE MAXIMUM INPUT FREQUENCY: 10 KHz
10. CONTROL INPUTS:
Reset: Active low (V
IL
= 1.5 V max.) internally pulled up to +12 VDC (I
SNK
= 3 mA), Activation and De-activation response time = 10 msec.
Program Disable: Active low (V
IL
= 1.5 V max.), internally pulled up to +5
VDC (I
SNK
= 1 mA).
Print Request: (GEM521xx only) Active low (V
IL
= 1.5 V max.), internally
pulled up to +5 VDC (I
SNK
= 1 mA).
11. SERIAL COMMUNICATIONS (Optional):
Type: Bi-directional 20 mA current loop, 20 mA source provided. (Powers
up to seven units in a loop with internal current source.)
Baud Rate: Programmable 300 to 2400.
Maximum Address: 16 units. (Actual number in a single loop is limited by
serial hardware specifications.)
Data Format: 10 bit frame, Odd parity (one start bit, 7 data bits, one odd
parity bit, and one stop bit.)
Serial Hardware Specifications:
SO - Output Transistor Rating: V
MAX
= 30 VDC, V
SAT
= 1 V
MAX
@
20 mA.
SI - Input Diode Rating: V
F
= 1.25 V
TYP
; 1.5 V
MAX
Note: The compliance voltage rating of the source must be greater than the
sum of the voltage drops around the loop.
12. OUTPUTS:
Solid-State: Current sinking NPN Open Collector Transistors. I
SNK
= 100
mA max. @ V
CE
= 1 V. V
OH
= 30 VDC max. (Internal Zener Diode
Protection).
Relays: Mounted on a field-replaceable PC board. Form C contacts rated at
5 A @ 120/240 VAC or 28 VDC (resistive load), 1/8 H.P. @120 VAC
(inductive load). The operate time is 5 msec nominal and the release time
is 3 msec nominal.
Relay Life Expectancy: 100,000 cycles at Max. Rating. (As load level
decreases, life expectancy increases.)
Programmed Timed Outputs: The timed outputs can be set from 0.01 to
599.99 seconds, ±(0.01% + 10 msec).
13. CERTIFICATIONS AND COMPLIANCES:
SAFETY
IEC 1010-1, EN 61010-1: Safety requirements for electrical equipment for
measurement, control, and laboratory use, Part 1.
IP65 Enclosure rating (Face only), IEC529
Type 4 Enclosure rating (Face only), UL50
ELECTROMAGNETIC COMPATIBILITY
Notes:
1. Metal bezel of unit connected with ground from rear bezel screw to metal
mounting panel.
2. When the unit is DC powered, a power line filter (RLC# LFIL0000 or
equivalent) was installed, so as not to impair the function of the unit.
Refer to the EMC Installation Guidelines section of the manual for additional
information.
14. ENVIRONMENTAL CONDITIONS:
Operating Temperature: 0 to 50°C
Storage Temperature: -40 to 70°C
Operating and Storage Humidity: 85% max. relative humidity (non-
condensing) from 0°C to 50°C.
Altitude: Up to 2000 meters
15. CONSTRUCTION:
Metal die-cast bezel, plastic case. This unit is rated for NEMA 4/IP65 indoor
use. Installation Category II, Pollution Degree 2.
16. WEIGHT: 2.1 lbs. (0.9 kg)
PROGRAMMABLE FUNCTIONS
UNIT PERSONALITY
Functions as a programmable Dual Rate Indicator, with or without speed
ratio, speed difference or draw indication.
PRESETS
Range 0 to ±999999
SCALE FACTORS
Separate 5-digit input scaling for both rate channels. Range 0.0001 to
5.9999.
SCALE MULTIPLIER
Multiplies the actual rate input by 1000, 100, 10, 1, 0.1, or 0.01 to view the
desired number of significant digits on the 6-digit display.
RESET OPERATION
Manual reset via front panel pushbutton or remote “RST” terminal can be
programmed to act on one or both outputs. A separate “RST.A” terminal is
available to provide independent reset of each channel. Front panel pushbutton
reset may be disabled by a switch at the rear of the unit. Reset only applies to
the outputs and has no effect on the sample time or the displayed value.
RIGHT-HAND DUMMY ZEROS
Up to three non-functional zeros may be placed on the least significant end
of the display when the unit is programmed in the dual rate only mode.
UPDATE TIME
The Rate Minimum Update Time is programmable from 0.5 to 16 seconds.
Provides averaging capability for non-consistent pulse spacing. Rate
Maximum Update Time will vary with the minimum time selected.
RATE CONVERSION FACTOR
Provides easy display conversion for readout in Rate Per Second, Rate Per
Minute, or Rate Per Hour.
DECIMAL POINT & LEADING ZERO BLANKING
Decimal point programmable to desired location. Leading zero blanking,
when selected, begins with second digit to the left of the decimal point.
OUTPUT TERMINATION MODES
Terminate at Manual Reset
Terminate at Manual Reset End
Terminate after Time Delay
Boundary
For positive preset value: Output terminates when Display is less than
Preset.
For negative preset value: Output terminates when Display is greater
than Preset, (i.e. more positive).
Note: In any of the above modes, the unit may be programmed for “Reverse
Phase” operation which complements the logic state of the output.
TIMED OUTPUTS
Programmable from 0.01 to 599.99 seconds. Accurate to ±(0.01% + 10
msec.).
FRONT PANEL LOCKOUT MODES
When the “Program Disable” control input is activated, the ability to
change front panel programmed functions will be prevented as per the
following modes:
Complete Front Panel Disabled
Presets Enabled Only
Scale Factors Enabled Only
Presets and Scale Factors Enabled
Note: Manual Reset may be independently enabled or disabled in any of the
above modes.
SELF-TEST
Performs a complete check on the display and output circuitry along with a
functional check on the CPU.
Immunity to EN 50082-2
Electrostatic discharge
EN 61000-4-2
Level 3; 10 V/m
Level 3; 8 Kv air
Electromagnetic RF fields EN 61000-4-3
80 MHz - 1 GHz
Level 4; 2 Kv I/O
EN 61000-4-4 Fast transients (burst)
Level 3; 2 Kv power 2
Level 3; 10 V/rms EN 61000-4-6 RF conducted interference
150 KHz - 80 MHz
Level 4; 30 A/m
EN 61000-4-8
Emissions to EN 50081-2
Enclosure class A
Power mains class A EN 55011 RF interference
Power frequency magnetic fields
Level 2; 4 Kv contact 1
