3

G

ENERAL

M

ETER

S

PECIFICATIONS

1. DISPLAY: 4-digit, 0.56" (14.2 mm) high red LED, minus sign displayed for

negative temperatures.
Overrange/Underrange Input: Flashing “



” or “



Overrange/Underrange Display: “” or “



2. POWER: 85 to 250 VAC, 50/60 Hz, 6 VA

Isolation: 2300 Vrms for 1 min. between input and supply (300 V working

voltage)

3. CONTROLS: Three front panel push buttons for meter set-up. Rear terminal

input for disabling the front panel.

4. RESOLUTION: 0.1 or 1 degree
5. RANGE: Decimal Point Dependent

0.1° res: -199.9° to 850.0 °C (-199.9° to 999.9 °F);
1° res: -200° to 850 °C (-328° to 1562 °F)

6. OPEN/SHORTED RTD DETECTION: Display flashes: “



” or “



7. LEAD RESISTANCE EFFECT: 20

 max., 2.5 °C/ error for V exc. and

common lead unbalance

8. ACCURACY: 0.3 °C, @ 23 °C and 30 min. warm-up
9. READING RATE: 2.5 readings/second
10. RESPONSE TIME: 2 seconds to settle for step input (increases with

programmable digital filtering)

11. LOW FREQUENCY NOISE REJECTION:

Normal Mode Rejection: 40 dB @ 50/60 Hz (may be improved by
programmable digital filtering)
Common Mode Rejection: 120 dB, DC to 50/60 Hz

12. CERTIFICATIONS AND COMPLIANCES:

SAFETY
UL Recognized Component, File # E179259, UL61010A-1, CSA C22.2 No. 61010-1

Recognized to U.S. and Canadian requirements under the Component
Recognition Program of Underwriters Laboratories, Inc.

UL Listed, File # E137808, UL508, CSA C22.2 No. 14-M95

LISTED by Und. Lab. Inc. to U.S. and Canadian safety standards
Type 4X Enclosure rating (Face only), UL50

IECEE CB Scheme Report # 04ME11209-20041018

Issued by Underwriters Laboratories, Inc.

IEC 61010-1, EN 61010-1: Safety requirements for electrical equipment

for measurement, control, and laboratory use, Part 1.

IP65 Enclosure rating (Face only), IEC 529

ELECTROMAGNETIC COMPATIBILITY
Emissions and Immunity to EN 61326: Electrical Equipment for Measurement,

Control and Laboratory use.

Note:

1. Criterion A: Normal operation within specified limits.

13. ENVIRONMENTAL CONDITIONS:

Operating Temperature Range: 0 to 50 °C
Storage Temperature Range: -40 to 80 °C
Operating and Storage Humidity: 85% max (non-condensing) from 0 to
50 °C
Span Drift: 50 ppm/ °C
Zero Drift: 0.001 °C/°C
Vibration According to IEC 68-2-6: Operational 5 to 150 Hz, in X, Y, Z

direction for 1.5 hours, 2 g’s.

Shock According to IEC 68-2-27: Operational 30 g’s, 11 msec in 3 directions.
Altitude: Up to 2000 meters.

14. CONSTRUCTION: This unit is rated for NEMA 4X/IP65 outdoor use. One

piece bezel/case. Flame resistant. Panel gasket and mounting clip included.

15. CONNECTIONS: High compression cage-clamp terminal block

Wire Strip Length: 0.3" (7.5 mm)
Wire Gage: 30-14 AWG copper wire
Torque: 4.5 inch-lbs (0.51 N-m) max.

16. WEIGHT: 0.65 lbs. (0.24 Kg)

Class B

EN 55011

Emissions

Emissions:

0.5 cycle

Criterion A

EN 61000-4-11

Voltage dip/interruptions

3 V/rms

Criterion A

EN 61000-4-6

RF conducted interference

1 kV signal

1 kV L-L,

Criterion A

EN 61000-4-5

Surge

2 kV signal

2 kV power

Criterion A

EN 61000-4-4

Fast transients (burst)

2 kV L&N-E power

10 V/m

Criterion A

EN 61000-4-3

Electromagnetic RF fields

8 kV air discharge

4 kV contact discharge

Criterion A

EN 61000-4-2

Electrostatic discharge

Immunity:

A

CCESSORIES

UNITS LABEL KIT (PAXLBK)

Each meter has a units indicator with backlighting that can be customized using

the Units Label Kit. The backlight is controlled in the programming.

Each meter is shipped with °F and °C overlay labels which can be installed into

the meter’s bezel display assembly.
