Page 2: Ontents

2
O
RDERING
I
NFORMATION
Meter Part Numbers
Ordering Information . . . . . . . . . . . . . . . . . . . . 2
General Meter Specifications . . . . . . . . . . . . . 3
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installing the Meter . . . . . . . . . . . . . . . . . . . . . 4
Wiring the Meter . . . . . . . . . . . . . . . . . . . . . . . 4
Reviewing the Front Buttons and Display . . . . 5
Programming the Meter. . . . . . . . . . . . . . . . . . 6
Calibrating the Meter . . . . . . . . . . . . . . . . . . . . 7
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . 7
T
ABLE
OF
C
ONTENTS
PAXL
0
0
RT - RTD Temperature Meter
RT
Accessories Part Numbers*
MODEL NO.
DESCRIPTION
PART NUMBERS
Accessories
TYPE
PAXLBK
Units Label Kit Accessory
PAXLBK30
*This meter is shipped with °F and °C overlay labels. The label kit is only
needed if another units label is desired.
