1. DISPLAY: 3 1/2-digit, 0.56" (14.2 mm) high, 7-segment red LED, (-) minus
sign displayed when current or voltage is negative. Decimal points inserted
before 1st, 2nd, or 3rd least significant digits by DIP switch selection.
2. POWER: 115/230 VAC, switch selectable. Allowable power line variation
±10%, 50/60 Hz, 6 VA.
Isolation: 2300 Vrms for 1 min. between input and supply
Working Voltage: 300 V max. , CAT II
3. INPUT RANGES/RESOLUTION: (Selectable by jumper connections.):
Input Impedance:
Voltage: All ranges1M 
Current: 199.9 μA 1000.1 K 
1.999 mA 100.1 
19.99 mA 10.1 
199.9 mA 1.1 
1.999 A 0.1 
Working Voltage: 300 V max., CAT II
4. ACCURACY:
AC Voltmeters: ±(0.1% of Reading + 3 digits) (45-500 Hz)
AC Current Meters (45-500 Hz):
199.9 μA/199.9 mV, 1.999 mA, 19.99 mA: ±(0.1% of Reading + 3 digits)
199.9 mA: ±(0.15% of Reading + 3 digits)
1 A: ±(0.5% of Reading + 3 digits)
DC Voltmeters: ±(0.1% of Reading + 1 digit)
DC Current Meters:
199.9 μA/199.9 mV, 1.999 mA, 19.99 mA: ±(0.1% of Reading + 1 digit)
199.9 mA: ±(0.15% of Reading + 1 digit)
1.999 A: ±(0.5% of Reading + 1 digit)
Note: Any individual range may be recalibrated (scaled) to 0.1% accuracy
with appropriate calibration equipment.
5. OVER-RANGE INDICATION: on all modes is indicated by blanking 3
least significant digits.
6. MAX. VOLTAGE ON LOWEST INPUT RANGE: 75 VAC or DC (Both
voltmeters and current meters).
7. MAX. VOLTAGE ON TERMINAL BLOCK: 300 VAC or DC (Both
voltmeters and current meters).
8. MAX. CURRENTS (FOR CURRENT METERS):
199.9 μA through 19.99 mA: 10 times max. range current
199.9 mA: 1 A
1.999 A: 3 A
Caution: In circuits where fault currents can exceed the maximum shunt
current, a fast-blow fuse should be installed in series with the input signal.
Otherwise, a slow blow 10 amp fuse is recommended that will allow for
start-up over current situations, while still protecting the instrument.
9. TEMPERATURE COEFFICIENTS:
Current meters Voltmeters
DC:  100 PPM/ ° C DC:  75 PPM/ ° C
AC:  200 PPM/ ° C AC:  150 PPM/ ° C
10. ENVIRONMENTAL CONDITIONS:
Operating Temperature: 0° to 60 °C
Storage Temperature: -40° to 80 °C
Operating and Storage Humidity: 85% max. relative humidity (non-
condensing)
Vibration According to IEC 68-2-6: Operational 5 to 150 Hz, in X, Y, Z
direction for 1.5 hours, 2g.
Shock According to IEC 68-2-27: Operational 30 g, 11 msec in 3 directions.
Altitude: Up to 2000 meters
11. RESPONSE TIME TO STEP CHANGE INPUT: 1 sec. nominal
12. READING RATE: 2.5 readings/sec., nominal
13. NORMAL MODE REJECTION: 50 dB 50/60 Hz (DC units only)
14. COMMON MODE REJECTION: 110 dB DC or 50/60 Hz (DC units only)
15. COMMON MODE VOLTAGE (COMM. TO EARTH): 350 volt peak
16. CERTIFICATIONS AND COMPLIANCES:
SAFETY
UL Recognized Component, File #E179259, UL61010A-1, CSA C22.2
No. 61010-1
Recognized to U.S. and Canadian requirements under the Component
Recognition Program of Underwriters Laboratories, Inc.
UL Listed, File #E137808, UL508, CSA C22.2 No. 14-M95
LISTED by Und. Lab. Inc. to U.S. and Canadian safety standards
Type 4X Enclosure rating (Face only), UL50
IECEE CB Scheme Test Report #04ME11209-20041018
Issued by Underwriters Laboratories, Inc.
IEC 61010-1, EN 61010-1: Safety requirements for electrical equipment
for measurement, control, and laboratory use, Part 1.
IP65 Enclosure rating (Face only), IEC 529
ELECTROMAGNETIC COMPATIBILITY:
Emissions and Immunity to EN 61326: Electrical Equipment for Measurement,
Control and Laboratory use.
Notes:
1. Criterion A: Normal operation within specified limits.
2. Criterion B: Temporary loss of performance from which the unit self-
recovers.
17. CONNECTIONS: High compression cage-clamp terminal block
Wire Strip Length: 0.3" (7.5 mm)
Wire Gage: 30-14 AWG copper wire
Torque: 4.5 inch-lbs (0.51 N-m) max.
18. CONSTRUCTION: This unit is rated for NEMA 4X/IP65 outdoor use.
Installation Category II, Pollution Degree 2. One piece bezel/case. Flame
resistant. Panel gasket and mounting clip included.
19. WEIGHT: 0.65 lbs. (0.24 Kg)
3
G
ENERAL
M
ETER
S
PECIFICATIONS
AC Voltmeters AC Current Meters DC Voltmeters DC Current Meters
0-1.999 V/1 mV 0-199.9 μA/0.1 μA 1.999 V/1 mV 199.9 μA/0.1 μA
0-19.99 V/10 mV 0-1.999 mA/1 μA 19.99 V/10 mV 1.999 mA/1 μA
0-19.99 mA/10 μA 199.9 V/100 mV 19.99 mA/10 μA
0-300 V/1 V 0-199.9 mA/100 μA 300 V/1 V 199.9 mA/100 μA
1.999 A/1 mA
0-199.9 mV/100 μV 199.9 mV/100 μV
0-1.999 A/1 mA
A
CCESSORIES
UNITS LABEL KIT (PAXLBK)
Each meter has a units indicator with backlighting that can be customized
using the Units Label Kit. The backlight is controlled by a DIP switch.
EXTERNAL CURRENT SHUNTS (APSCM)
To measure DC current signals greater than 2 ADC, a shunt must be used. The
APSCM010 current shunt converts a maximum 10 ADC signal into 100.0 mV.
The APSCM100 current shunt converts a maximum 100 ADC signal into 100.0
mV. The continuous current through the shunt is limited to 115% of the rating.
Class B EN 55011 Emissions
Emissions:
0.5 cycle; 40 % variation
Criterion A EN 61000-4-11 Voltage dip/interruptions
3 V/rms
Criterion A EN 61000-4-6 RF conducted interference
1 kV L-L,
Criterion A EN 61000-4-5 Surge
2 kV signal
2 kV power
Criterion B EN 61000-4-4 Fast transients (burst)
2 kV L&N-E power
10 V/m
Criterion B EN 61000-4-3 Electromagnetic RF fields
8 kV air discharge
4 kV contact discharge
Criterion A EN 61000-4-2 Electrostatic discharge
Immunity to Industrial Locations:
0-199.9 V/100 mV
