-37-
USER/FACTORY SETTINGS
This module should only be entered if the operator wants to reset ALL
parameters to the factory settings. When the word “FACTORY” is flashing in
the display and the ENT key is pressed, all parameters will be set to the factory
settings when exiting the programming loop. The operator can exit the
factory settings option WITHOUT resetting all parameters by pressing the
along with a chart for user settings:
Caution: If factory settings are selected, all programming by the user will be
reset.
OUTPUT 1
ASSIGNED TO CNT
PHASE +
TYPE TIMED
ACT/TIME 0.10
OUTPUT END DISABLED
DLY TYPE
ON DL TIME
OF DL TIME
OFF@P.
UP
RST/C EN
REQ MSG #
OUTPUT 4
ASSIGNED TO CNT
PHASE +
TYPE TIMED
ACT/TIME 0.10
DLY TYPE
ON DL TIME
OF DL TIME
OFF@P.
UP
RST/C EN
REQ MSG #
OUTPUTS
OUTPUT 2
ASSIGNED TO CNT
PHASE +
TYPE TIMED
ACT/TIME 0.10
OUTPUT END DISABLED
DLY TYPE
ON DL TIME
OF DL TIME
OFF@P.
UP
RST/C EN
REQ MSG #
OUTPUT 5
ASSIGNED TO CNT
PHASE +
TYPE TIMED
ACT/TIME 0.10
DLY TYPE
ON DL TIME
OF DL TIME
OFF@P.
UP
RST/C EN
REQ MSG #
OUTPUT 3
ASSIGNED TO CNT
PHASE +
TYPE TIMED
ACT/TIME 0.10
DLY TYPE
ON DL TIME
OF DL TIME
OFF@P.
UP
RST/C EN
REQ MSG #
OUTPUT 6
ASSIGNED TO CNT
PHASE +
TYPE TIMED
ACT/TIME 0.10
DLY TYPE
ON DL TIME
OF DL TIME
OFF@P.
UP
RST/C EN
REQ MSG #
SCALE FACTORS
COUNT SF 1.0000
RATE SF 1.0000
CNT. SCM X 1
CNT. D.P. 0
RATE SCM X 1
RATE PER SECOND
RATE D.P. 0
CHG. CNT/
WITH SF
YES
RATE
MIN. TIME 1.0
MAX. TIME 5.0
COUNTER
CNT. INPUT CT+DIRX1
RESET TO ZERO
AUTO. RST DISABLED
LGPM FACTORY SETTINGS CHART
USER INPUTS
BIN. MSG.REQ. NONE
USER INP. 1 NO MODE
USER INP. 2 NO MODE
USER INP. 3 NO MODE
USER INP. 4 INHIBIT
USER F1 MNT RST
RATE-NO
PEAK-YES
VALLEY-YES
COUNT-NO
USER F2 MNT RST
RATE-NO
PEAK-NO
VALLEY-NO
COUNT-YES
